14K TAND LP DUMP 83"x14 7SIR Black
VIN: 033127
Call for Quote
(507) 373-2464Albert Lea, MN
Tough as nails for the toughest, most demanding projects, the 14LP Heavy Duty Low Profile Dump Trailer is designed for the construction workers and those transporting large quantities of materials or equipment. And while its built to handle heavy-duty hauling tasks, its also packed with features to make the toughest jobs easier such as an ultra-low profile deck and side step to provide convenience and ease of use during loading, unloading, and transportation of materials.
- Overview
- Features/Specifications
- Standard/Optional Equipment
- Financing
Overview
14K TAND LP DUMP 83"x14 7SIR Black
Tough as nails for the toughest, most demanding projects, the 14LP Heavy Duty Low Profile Dump Trailer is designed for the construction workers and those transporting large quantities of materials or equipment. And while its built to handle heavy-duty hauling tasks, its also packed with features to make the toughest jobs easier such as an ultra-low profile deck and side step to provide convenience and ease of use during loading, unloading, and transportation of materials.
- Max Payload:
- 9790 lbs.
- Weight:
- 4210
- Category:
- Dump Trailers
- Year:
- 2018
- Condition:
- New
- Color:
- Black
- GVWR:
- 14000
- Capacity:
- 9790
Features/Specifications
Features
| Axle | (2) 7,000# Axles w/ Quick Lubricating Hubs and Elec. Brakes |
|---|---|
| Jack | 12,000# Side Wind Drop Leg |
| Tire | ST235/80 R-16 Load Range E |
| Floor | 10 Gauge Smooth Steel |
| Wheel | 16" x 6"; HD Black Mod 8 Bolt |
| Finish | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| Lights | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| Tongue | Integral with Frame (8" I-Beam, 10#) |
| Coupler | Adjustable 2-5/16" 18,000# Demco EZ Latch |
| Fenders | 9" x 72" 14Ga.Diamond Plate Double Square Broke |
| G.V.W.R. | 14,000# |
| Elec. Plug | 7-Way RV |
|---|---|
| Hitch Type | Bumper Pull |
| Main Frame | 8" I-Beam, 10# |
| Suspension | Multi-Leaf Spring w/Equalizer |
| Bed Top Rail | 2" x 2" Square Tubing |
| Finish (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| Safety Chains | 3/8" Grd. 70 w/Safety Latch Hook (2 each) |
| Dump Body Sides | 24" Tall Sides (10 Gauge) |
| G.A.W.R. (Ea. Axle) | 7,000# |
| Dump Body Crossmembers | 3" Channel, 16" Centers |
Specifications
Big Tex 14LP Heavy Duty Low Profile Dump Trailer
| Model | Description |
|---|---|
| 14LP-14 | 83" x 14' Heavy Duty Ultra Low Profile Dump |
| 14LP-16 | 83" x 16' Heavy Duty Ultra Low Profile Dump |
| 14LP-12 | 83” x 12’ Heavy Duty Ultra Low Profile Dump |
Dimensions
| Length | A | B | C |
|---|---|---|---|
| 14' | 168" | 100" | 68" |
| 16' | 192" | 115 3/4" | 76 1/4" |
| 12' |
Trailer Weights & Capacities
| Length | Empty Weight | Payload | Box Capacity |
|---|---|---|---|
| 14' | 4,180# | 9,820# | 7 Cubic Yards |
| 16' | 4,640# | 9,360# | 8 Cubic Yards |
| 12' | 3,870# | 10,130# | N/A |
Standard/Optional Equipment
Standard Equipment
- Adjustable 2-5/16" Demco EZ Latch Coupler
- 8" I-Beam Frame w/Integrated Tongue
- 28" Deck Height
- 12,000" Top Wind Drop-Leg Jack
- Lockable Pump & Battery Box Mounted in Front of Bed
- 24" Tall, 10 Gauge Sides w/Fomred Channel Supports
- 10 Gauge Steel Floors & Sides
- Fully Formed Tarp Shroud on Front
- Crank Style Roll Tarp- Standard Equipped
- Tarp Rod Included to Secure Tarp on Rear
- J-Hooks on sSides & Rear for Tarp Control
- Stakepockets Along Sides
- Self Contained Electric/Hydraulic Scissor Hoist
- Power Up/Power Down Hydraulic Pump
- 12V Interstate Deep Cycle Battery
- 110V On-Board Battery Charger (5 Amp)
- Premium Brand Axles
- Cambered Axles w/Quick Lubricating Hubs
- Forward Self Adjusting Electric Brakes on All Hubs
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Sealed, Modular Wiring Harness
- Complete Brake Away System
- Zip Breakaway Cable
- Diamond Plate Fenders
- 2" Square Tubing Top Rail on Dump Bed
- Combo Gate (Barn Doors & Spreader Gate)
- Rear Stabilizer Stands
- (4) 1/2" D-Rings Inside Bed to Secure Equipment
- Spare Tire Mount
- Radial Tires
Optional Equipment
| Category | Description |
|---|---|
| AXLE | Drop Axles (Lowers Deck Height to 24" from Ground) |
| BODY | 24" Expanded Metal Side Extensions |
| BODY | 3 Solid Sheet Metal Sides |
| BODY | 4 Solid Sheet Metal Sides |
| BODY | Upgrade Floor to 7-Gauge Steel |
| COUPLER | Adjustable Pintle in Channel ILO Coupler |
| JACKS | 12,000# Elec/Hyd. Jack BY Stillwell |
| POWER | 5 Watt Solar Charger |
| POWER | Wireless Remote |
| RAMPS | 6.5 Slide In Ramps |
| TIRE/WHEEL | Spare Tire (ST235/80 R-16 LR-E) |
| TIRE/WHEEL | Tire Upgrade (ST235/85 R-16 LR-G) |
